What is a Vector Display?

What is a Vector Display?

Welcome to our “Definitions” blog series where we break down complex concepts and explain them in simple terms. In this edition, we’ll be delving into the fascinating world of vector displays. So, what exactly is a vector display and what makes it so captivating?

Key Takeaways:

  • A vector display is a type of visual display technology that renders images and text using mathematical equations and geometric shapes.
  • Unlike raster displays, which use pixels to create images, vector displays offer infinite scalability and are ideal for generating crisp, smooth, and precise graphics.

A vector display is a display technology that brings graphics to life using mathematical equations and geometric shapes. Unlike traditional displays that rely on pixels, a vector display creates images and text by defining lines and curves in terms of their relative positions and orientations.

Vector displays have been around since the early days of computing, gaining popularity during the era when mainframe computers ruled the digital landscape. In those days, vector displays were commonly used for scientific and engineering applications due to their ability to provide accurate and precise representations of mathematical models and simulations.

So, how does a vector display work? Here’s a breakdown:

  1. Definition of primitives: The display system defines various geometric primitives, such as lines, circles, and polygons. These primitives serve as the building blocks for generating complex images.
  2. Mathematical equations: The display system uses mathematical equations to define the position, length, angle, and other properties of these geometric primitives.
  3. Rasterization: The display system processes these mathematical equations and rasterizes the vectors, converting them into a series of pixels for display on the screen.
  4. Rendering: The rasterized vectors are then rendered on the display, producing smooth lines, curves, and text.

One of the key advantages of vector displays is their infinite scalability. Since the images are defined mathematically rather than being based on fixed pixels, they can be scaled up or down without losing any detail or becoming pixelated. This makes vector displays particularly useful in applications that require precise and high-resolution graphics, such as CAD (Computer-Aided Design), GIS (Geographic Information System), and scientific visualizations.

Vector displays have also found their way into the gaming industry, adding a unique aesthetic to classic arcade games like Asteroids and Tempest. The distinctive lines, smooth movements, and sharp angles created by vector displays create a visually striking experience that still captivates enthusiasts to this day.

In summary, a vector display is a remarkable visual display technology that uses mathematical equations and geometric shapes to generate images and text. With their infinite scalability and ability to produce crisp graphics, vector displays continue to hold a special place in technology, art, and gaming.
